TRACOPOWER THM 30 30W Isolated DC-DC Converter Through Hole, Voltage in 18 → 36 V dc, Voltage out 12V dc Medical [THM 30-2412]; 165-1237
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 12V dc |
| Output Voltage Adjustment Range | ±10% |
| Input Voltage Range | 18 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 5kV ac |
| Power Rating | 30W |
| Output Current | 2.5A |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Medical Approved | Yes |
| Package | 2 x 1 in |
| Minimum Temperature | -40°C |
| Load Regulation | 0.002 |
| Maximum Temperature | +80°C |
| Length | 50.8mm |
| Series | THM 30 |
| Standards Met | ANSI/AAMI ES 60601-1, CB Scheme IEC 60601-1, CULus Recognised, EMC, EN 55011, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, ES60601-1, IEC 60601-1-2, IEC/EN 60601-1, MIL-STD-810F |
| Depth | 10.2mm |
| Width | 25.4mm |
