TRACOPOWER THN 15WIR 15W Isolated DC-DC Converter PCB Mount, Voltage in 36 → 110 V dc, Voltage out ±15V dc [THN 15-7223WIR]; 135-1564
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±15V dc |
| Output Voltage Adjustment Range | ±13.5 V dc, ±18 V dc |
| Input Voltage Range | 36 → 110 V dc |
| Input Voltage Nominal | 72 V dc |
| Isolation Voltage | 3kV dc |
| Power Rating | 15W |
| Output Current | ±500mA |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Railway Approved | Yes |
| Package | DIP-6 |
| Load Regulation | 0.01 |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Standards Met | CB Scheme, CE Certified, CULus Recognised, EMI 55022 Class A, EN 45545-2, IEC/EN 60950-1, UL 60950-1 |
| Width | 25.4mm |
| Depth | 9.9mm |
| Length | 25.4mm |
| Series | THN 15WIR |
