TRACOPOWER TVN 5WI 5W Isolated DC-DC Converter Through Hole, Voltage in 18 → 75 V dc, Voltage out ±24V dc [TVN 5-4825WI]; 146-5979
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±24V dc |
| Output Voltage Adjustment Range | ±21.6 V dc, ±26.4 V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 5W |
| Output Current | ±100mA |
| Isolation Voltage | 1.6kV dc |
| Input Voltage Nominal | 48 V dc |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Efficiency | 0.87 |
| Package | DIP-24 |
| Minimum Temperature | -40°C |
| Load Regulation | 0.01 |
| Maximum Temperature | +85°C |
| Series | TVN 5WI |
| Standards Met | EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN/UL 60950-1, MIL-STD-810F |
| Width | 20mm |
| Length | 32mm |
| Depth | 10.2mm |
