Vishay 33 μH ±20% Leaded Inductor, Max SRF:4.58MHz, 9.5A Idc, 23.8mΩ Rdc IHTH-0750IZ-5A [IHTH0750IZEB330M5A]; 123-1529
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 33 μH |
| Maximum DC Current | 9.5A |
| Mounting Type | Radial |
| Maximum DC Resistance | 23.8mΩ |
| Tolerance | ±20% |
| Diameter | 19.17mm |
| Height | 8.7mm |
| Dimensions | 19.17 (Dia.) x 8.7mm |
| Maximum Self Resonant Frequency | 4.58MHz |
| Lead Pitch | 12.11mm |
| Series | IHTH-0750IZ-5A |
| Minimum Operating Temperature | -55°C |
| Terminal Type | Radial Leaded |
| Maximum Operating Temperature | +155°C |
| Lead Diameter | 1.01mm |
