Vishay 3.3 μH ±20% Leaded Inductor, Max SRF:16.7MHz, 40A Idc, 2.4mΩ Rdc IHTH-0750IZ-5A [IHTH0750IZEB3R3M5A]; 173-3897
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 3.3 μH |
| Maximum DC Current | 40A |
| Mounting Type | Radial |
| Maximum DC Resistance | 2.4mΩ |
| Tolerance | ±20% |
| Diameter | 19.17mm |
| Height | 8.7mm |
| Dimensions | 19.17 (Dia.) x 8.7mm |
| Maximum Self Resonant Frequency | 16.7MHz |
| Lead Pitch | 11.7mm |
| Series | IHTH-0750IZ-5A |
| Terminal Type | Radial Leaded |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +155°C |
| Lead Diameter | 1.6mm |
