Vishay 8.2 μH ±20% Leaded Inductor, Max SRF:11.6MHz, 20A Idc, 6.14mΩ Rdc IHTH-0750IZ-5A [IHTH0750IZEB8R2M5A]; 173-1549
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 8.2 μH |
| Maximum DC Current | 20A |
| Mounting Type | Radial |
| Maximum DC Resistance | 6.14mΩ |
| Tolerance | ±20% |
| Diameter | 19.17mm |
| Height | 8.7mm |
| Dimensions | 19.17 (Dia.) x 8.7mm |
| Maximum Self Resonant Frequency | 11.6MHz |
| Lead Pitch | 10.84mm |
| Series | IHTH-0750IZ-5A |
| Lead Diameter | 1.2mm |
| Terminal Type | Radial Leaded |
| Maximum Operating Temperature | +155°C |
| Minimum Operating Temperature | -55°C |
