IRF540PBF N-Channel MOSFET, 28 A, 100 V, 3-Pin TO-220AB Vishay [IRF540PBF]; 708-5143
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 28 A |
| Maximum Drain Source Voltage | 100 V |
| Package Type | TO-220AB |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Maximum Drain Source Resistance | 77 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 2V |
| Maximum Power Dissipation | 150 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Typical Gate Charge @ Vgs | 72 nC @ 10 V |
| Height | 9.01mm |
| Minimum Operating Temperature | -55 °C |
| Transistor Material | Si |
| Width | 4.7mm |
| Maximum Operating Temperature | +175 °C |
| Length | 10.41mm |
