IRLD014PBF N-Channel MOSFET, 1.7 A, 60 V, 4-Pin HVMDIP Vishay [IRLD014PBF]; 178-0922
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 1.7 A |
| Maximum Drain Source Voltage | 60 V |
| Package Type | HVMDIP |
| Mounting Type | Through Hole |
| Pin Count | 4 |
| Maximum Drain Source Resistance | 200 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 1.3 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -10 V, +10 V |
| Number of Elements per Chip | 1 |
| Transistor Material | Si |
| Length | 5mm |
| Typical Gate Charge @ Vgs | 8.4 nC @ 5 V |
| Minimum Operating Temperature | -55 °C |
| Width | 6.29mm |
| Height | 3.37mm |
| Maximum Operating Temperature | +175 °C |
