Vishay KBP04M-E4/51, Bridge Rectifier, 1.5A 400V, 4-Pin KBPM [KBP04M-E4/51]; 170-8419
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Peak Average Forward Current | 1.5A |
| Bridge Type | Single Phase |
| Peak Reverse Repetitive Voltage | 400V |
| Mounting Type | Through Hole |
| Package Type | KBPM |
| Pin Count | 4 |
| Diode Technology | Silicon Junction |
| Configuration | Single |
| Peak Non-Repetitive Forward Surge Current | 60A |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -55 °C |
| Peak Forward Voltage | 1.3V |
| Peak Reverse Current | 500µA |
| Length | 15.24mm |
| Width | 5.08mm |
| Dimensions | 15.24 x 5.08 x 11.68mm |
| Junction Capacitance | 15pF |
| Height | 11.68mm |
