Vishay 22μF 35V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 5.5 x 5.5 x 6.1mm 5mm 1.4mm 5.5mm [MAL218297001E3]; 174-0162
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 35 V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 5.5 x 5.5 x 6.1mm |
| Height | 6.1mm |
| Length | 5.5mm |
| Depth | 5.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 1.4mm |
| Lifetime | 160000 h @ +65 °C |
| Series | 182 CPHZ |
| Tolerance | ±20% |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance | 100mΩ |
| Dissipation Factor | 0.0012 |
| Leakage Current | 7.7 μA |
| Ripple Current | 900mA |
| Polarised | Polar |
