Vishay 22μF 63V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 6.7 x 6.7 x 8mm 6.3mm 2.2mm 6.7mm [MAL218297802E3]; 174-0168
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 63 V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 6.7 x 6.7 x 8mm |
| Height | 8mm |
| Length | 6.7mm |
| Depth | 6.7mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 2.2mm |
| Lifetime | 160000 h @ +65 °C |
| Series | 182 CPHZ |
| Leakage Current | 13.9 μA |
| Ripple Current | 1.5A |
| Equivalent Series Resistance | 80mΩ |
| Tolerance | ±20% |
| Automotive Standard | AEC-Q200 |
| Dissipation Factor | 0.0008 |
| Polarised | Polar |
