Vishay 56μF 63V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 10.5 x 10.5 x 10.8mm 10mm 4.5mm 10.5mm [MAL218297804E3]; 174-0546
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 56 µF |
| Voltage | 63 V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 10.5 x 10.5 x 10.8mm |
| Height | 10.8mm |
| Length | 10.5mm |
| Depth | 10.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 160000 h @ +65 °C |
| Lead Pitch | 4.5mm |
| Series | 182 CPHZ |
| Automotive Standard | AEC-Q200 |
| Leakage Current | 35.3 μA |
| Tolerance | ±20% |
| Polarised | Polar |
| Ripple Current | 1.8A |
| Equivalent Series Resistance | 30mΩ |
| Dissipation Factor | 0.0008 |
