Vishay 12μF 80V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 8.5 x 8.5 x 12mm 8mm 3.1mm 8.5mm [MAL218497701E3]; 174-0534
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 12 µF |
| Voltage | 80 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 8.5 x 8.5 x 12mm |
| Height | 12mm |
| Length | 8.5mm |
| Depth | 8.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 3.1mm |
| Lifetime | 200000 h @ 65 °C |
| Series | 184 CPNS |
| Tolerance | ±20% |
| Automotive Standard | AEC-Q200 |
| Polarised | Polar |
| Leakage Current | 192 μA |
| Dissipation Factor | 0.0012 |
| Equivalent Series Resistance | 40mΩ |
| Ripple Current | 1.8A |
