VISHAY Transistor: N-MOSFET x2; TrenchFET®; unipolar; 40V; 6A; Idm: 20A [SI7216DN-T1-E3]
The Vishay SI7216DN is a dual N-channel MOSFET having drain to source(Vds) voltage of 40V.The gate to source voltage(VGS) is 20V. It is having power PAK 1212-8 package. It offers drain to source resistance (RDS.) 0.032ohms at 10VGS and 0.039ohms at 4.5VGS. Maximum drain current 6A. Trench FET power MOSFET Low thermal resistance Power PAK package with small size and low 1.07 mm profile 100 % Rg and UIS tested Compliant to RoHS directive 2002/95/EC
The Vishay SI7216DN is a dual N-channel MOSFET having drain to source(Vds) voltage of 40V.The gate to source voltage(VGS) is 20V. It is having power PAK 1212-8 package. It offers drain to source resistance (RDS.) 0.032ohms at 10VGS and 0.039ohms at 4.5VGS. Maximum drain current 6A.
Trench FET power MOSFET
Low thermal resistance Power PAK package with small size and low 1.07 mm profile
100 % Rg and UIS tested
Compliant to RoHS directive 2002/95/EC
