| Logic Family |
HC |
| Logic Function |
Buffer, Line Driver |
| Number of Channels per Chip |
8 |
| Input Type |
Single Ended |
| Output Type |
3 State |
| Polarity |
Inverting |
| Mounting Type |
Surface Mount |
| Package Type |
SOIC |
| Pin Count |
20 |
| Maximum High Level Output Current |
-7.8mA |
| Maximum Low Level Output Current |
7.8mA |
| Maximum Propagation Delay Time @ Maximum CL |
150 ns @ 2 V |
| Dimensions |
12.8 x 7.52 x 2.35mm |
| Height |
2.35mm |
| Maximum Operating Temperature |
+85 °C |
| Propagation Delay Test Condition |
150pF |
| Length |
12.8mm |
| Maximum Operating Supply Voltage |
6 V |
| Width |
7.52mm |
| Minimum Operating Supply Voltage |
2 V |
| Minimum Operating Temperature |
-40 °C |
