KEYSIGHT TECHNOLOGIESDSOX2012AInfiniiVision 2000 X Series DSOX2012A Oscilloscope, Bench, 2 Channels, 100MHz

Bandwidth 100MHzKiểu màn hình Capacitive Touch DisplayMaximum Vertical Sensitivity 5V/divMinimum Time Base 5ns/div
Mã nhà sản xuất
DSOX2012A
Thương hiệu
Quy cách đóng gói
1 cái
Mã kho
7250489
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Keysight Technologies Oscilloscope, 8.5in Display, 100W Power Line Consumption - InfiniiVision 2000 X Series - DSOX2012A

Get a clear read on electrical signals with this oscilloscope from Keysight Technologies. Its waveform update rate of 200,000 waveforms per second means you'll always get the most up-to-date results. Monitoring your signal is a breeze thanks to this unit's easy-to-read 8.5-inch LCD screen. The device supports 25 automated measurements, including time, voltage and waveform math functions, so it's a versatile piece of kit. It's compatible with BenchVue software, which makes data collection and analysis as easy as can be.

Features & Benefits

  • Memory of 1Mpt per channel for storing large amounts of data
  • Compact dimensions of 204 (H) x 381 (W) x 142mm (D) to take up minimal space in your setup

Applications

  • Automotive manufacturing
  • Data storage device testing
  • Reflectometry

Does this unit have a USB port?

Yes, this oscilloscope has two high-speed USB host ports on the front and rear panels and a single device port supporting USBTMC protocol on the back. This makes it easy to connect to a computer for data transfer and analysis.

Note

Manufacturer's Warranty

THÔNG SỐ KỸ THUẬT
Number of Channels 2
Bandwidth 100MHz
Oscilloscope Type Bench
Series InfiniiVision 2000 X
Power Source Mains
Display Type Capacitive Touch Display
Minimum Vertical Sensitivity 1mV/div
Maximum Vertical Sensitivity 5V/div
Minimum Time Base 5ns/div
Screen Size 8.5in
Sample Rate Random 2 Gsps
Plug Type Type C - European Plug, Type G - British 3-pin
Safety Category Voltage 300V
Model Number p DSOX2012A
Safety Category Level CAT I, CAT II
Safety Category CAT I 300 V, CAT II 300 V
Vertical Resolution 8 bit
