HARWINM80-8501045M80 Series 2mm Pitch 10 Way 2 Row Straight PCB Socket, Through Hole, Solder Termination

Hướng thân StraightVật liệu tiếp điểm Beryllium CopperDòng định mức 3AKiểu lắp Through Hole
Mã nhà sản xuất
M80-8501045
Thương hiệu
Quy cách đóng gói
1 cái
Mã kho
511373
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

DIL Socket - Vertical PC Tail

This range of L-Tek DIL 180° PC tail Headers are part of the Datamate Series from Harwin.

M80-850xx42 have Gold plated Clips and Tin plated Shells

M80-850xx45 have Gold plated Clips and Shells

2.0mm Datamate Series

The Datamate range is ideal for applications where safety is key, the application is subject to high loads of vibration, shock and acceleration or operates in harsh environments. These Datamate connectors are highly durable and can withstand high numbers of mating cycles without any degradation in performance. This performance is made possible by Harwin's use of High Reliability four finger Beryllium Copper contacts in the Datamate range. These contacts feature a 4 finger clip to ensure integrity of connection under the most severe conditions.

Polarised mouldings

High reliability connector system

The L-Tek Datamate connectors are available with or without Latches.

Mates with known industry equivalents

Suited for COTS applications

Complies with BS9525-F0033/MIL C 55302/CEC 75101-008

THÔNG SỐ KỸ THUẬT
Number of Contacts 10
Number of Rows 2
Pitch 2mm
Type Board to Board
Mounting Type Through Hole
Body Orientation Straight
Termination Method Solder
Current Rating 3A
Voltage Rating 120 V ac/dc
Series M80
Contact Material Beryllium Copper, Brass
