KEMETALC80A103CD04010000μF Electrolytic Capacitor 40V dc, Snap-In - ALC80A103CD040

Điện dung 10000µFĐường kính 30mmKhoảng cách chân 10mmLeakage Current 1.2mA
Mã nhà sản xuất
ALC80A103CD040
Thương hiệu
Quy cách đóng gói
Khay 160 cái
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The KEMET ALC80 High CV snap-in capacitors offer high performance and reliability in a wide range of case sizes and voltage ratings featuring high ripple currents and long-life performance. Volumetric efficiency ensures the maximum capacitance capability in a smaller size.

Maximum capacitance capability in a smaller size

Long life, up to 9,000 hours at +105°C (VR,IR applied)

High ripple current

Excellent surge voltage capability

Applications

Typical applications for the ALC80 capacitor includes alternative energy, smoothing, energy storage, or pulse operation in telecommunications, demanding power supplies (SMPS), process control, AC motor control, traction, welding, frequency converters, uninterruptible power supply (UPS) systems, and measuring.

THÔNG SỐ KỸ THUẬT
Manufacturer KEMET
Manufacturer Part No. ALC80A103CD040
Capacitance 10000µF
Voltage 40V dc
Mounting Type Snap-In
Technology Electrolytic
Dimensions 30 Dia. x 40mm
Depth 40mm
Minimum Operating Temperature -40°C
Diameter 30mm
Maximum Operating Temperature +105°C
Lifetime 30000h
Lead Pitch 10mm
Equivalent Series Resistance 51Ω
Tolerance ±20%
Leakage Current 1.2mA
Series ALC80
Ripple Current 9.2A
Polarised Polar

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.

Compare products

Select 2 or 3 items to compare

Select first item to compare

Select second item to compare

Select third item to compare

Compare
📄 Datasheet KEMET 10000μF Electrolytic Capacitor 40V dc, Snap-In - ALC80A103CD040 (PDF)
