MICROCHIPMIC5891YWM-TRMIC5891YWM-TR 8bit-Bit Latch, Transparent RS-Latch, 16-Pin SOIC W

Latch Mode TransparentLatching Element RS-LatchLogic Family MICNumber of Bits 8bit
Mã nhà sản xuất
MIC5891YWM-TR
Thương hiệu
Quy cách đóng gói
Gói 5 cái
Mã kho
2097713
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Microchip MIC5891YWM-TR latched driver is a high-voltage, high current integrated circuit comprised of eight CMOS data latches, CMOS control circuitry for the common STROBE and OUTPUT ENABLE, and bipolar Darlington transistor drivers for each latch. Bipolar/MOS construction provides extremely low power latches with maximum interface flexibility. The MIC5891YWM-TR will typically operate at 5MHz with a 5V logic supply. The CMOS inputs are compatible with standard CMOS, PMOS, and NMOS logic levels. TTL circuits may be used with appropriate pull-up resistors to ensure a proper logic-high input. A CMOS serial data output allows additional drivers to be cascaded when more than 8 bits are required. The MIC5891YWM-TR has open-emitter outputs with suppression diodes for protection against inductive load transients. The output transistors are capable of sourcing 500mA and w

High-voltage, high-current outputs

Output transient protection diodes

CMOS-, PMOS-, NMOS-, and TTL-compatible inputs

Low-power CMOS latches

THÔNG SỐ KỸ THUẬT
Manufacturer Microchip
Manufacturer Part No. MIC5891YWM-TR
Logic Family MIC
Latch Mode Transparent
Latching Element RS-Latch
Number of Bits 8bit
Number of Elements per Chip 1
Number of Channels per Chip 1
Package Type SOIC W
Pin Count 16

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
