PANASONICEEEFN0J100R10μF Electrolytic Aluminium Electrolytic Capacitor 6.3V dc, Surface Mount - EEEFN0J100R

Điện dung 10µFĐường kính 4mmKhoảng cách chân 1mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN0J100R
Thương hiệu
Quy cách đóng gói
Cuộn 2000 cái
Mã kho
2043360
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 10 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN0J100R
Capacitance 10µF
Voltage 6.3V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 4 x 5.8mm
Length 5.8mm
Minimum Operating Temperature -55°C
Diameter 4mm
Maximum Operating Temperature +105°C
Lead Pitch 1mm
Equivalent Series Resistance 1.35Ω
Ripple Current 90mA
Tolerance ±20%
Series FN-V
Automotive Standard AEC-Q200
Polarised Polar

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
