PANASONICEEEFN1A100R10μF Electrolytic Aluminium Electrolytic Capacitor 10V dc, Surface Mount - EEEFN1A100R

Điện dung 10µFĐường kính 4mmKhoảng cách chân 1mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1A100R
Thương hiệu
Quy cách đóng gói
Cuộn 2000 cái
Mã kho
2043366
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 10 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1A100R
Capacitance 10µF
Voltage 10V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 4 x 5.8mm
Length 5.8mm
Minimum Operating Temperature -55°C
Diameter 4mm
Maximum Operating Temperature +105°C
Lead Pitch 1mm
Automotive Standard AEC-Q200
Ripple Current 90mA
Equivalent Series Resistance 1.35Ω
Tolerance ±20%
Polarised Polar
Series FN-V
