PANASONICEEEFN1A101UR100μF Electrolytic Aluminium Electrolytic Capacitor 10V dc, Surface Mount - EEEFN1A101UR

Điện dung 100µFĐường kính 5mmKhoảng cách chân 1.5mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1A101UR
Thương hiệu
Quy cách đóng gói
Cuộn 1000 cái
Mã kho
2043373
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 100 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1A101UR
Capacitance 100µF
Voltage 10V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 5 x 5.8mm
Length 5.8mm
Minimum Operating Temperature -55°C
Diameter 5mm
Maximum Operating Temperature +105°C
Lead Pitch 1.5mm
Polarised Polar
Ripple Current 160mA
Tolerance ±20%
Equivalent Series Resistance 700mΩ
Automotive Standard AEC-Q200
Series FN-V

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
