PANASONICEEEFN1A101UR100μF Aluminium Electrolytic Capacitor 10V dc, Surface Mount - EEEFN1A101UR

Điện dung 100µFĐường kính 5mmKhoảng cách chân 1.5mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1A101UR
Thương hiệu
Quy cách đóng gói
100 cái (băng liên tục)
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 100 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1A101UR
Capacitance 100µF
Voltage 10V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 5 x 5.8mm
Length 5.8mm
Diameter 5mm
Maximum Operating Temperature +105°C
Lead Pitch 1.5mm
Tolerance ±20%
Polarised Polar
Series FN-V

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
