PANASONICEEEFN1A821UP820μF Electrolytic Aluminium Electrolytic Capacitor 10V dc, Surface Mount - EEEFN1A821UP

Điện dung 820µFĐường kính 8mmKhoảng cách chân 3.1mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1A821UP
Thương hiệu
Quy cách đóng gói
100 cái (băng liên tục)
Mã kho
2043377
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 820 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1A821UP
Capacitance 820µF
Voltage 10V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 8 x 10.2mm
Length 10.2mm
Diameter 8mm
Maximum Operating Temperature +105°C
Lead Pitch 3.1mm
Polarised Polar
Tolerance ±20%
Series FN-V

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
