PANASONICEEEFN1E220R22μF Electrolytic Aluminium Electrolytic Capacitor 25V dc, Surface Mount - EEEFN1E220R

Điện dung 22µFĐường kính 4mmKhoảng cách chân 1mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1E220R
Thương hiệu
Quy cách đóng gói
Cuộn 2000 cái
Mã kho
2043387
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 22 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1E220R
Capacitance 22µF
Voltage 25V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 4 x 5.8mm
Length 5.8mm
Minimum Operating Temperature -55°C
Diameter 4mm
Maximum Operating Temperature +105°C
Lead Pitch 1mm
Polarised Polar
Series FN-V
Automotive Standard AEC-Q200
Ripple Current 90mA
Equivalent Series Resistance 1.35Ω
Tolerance ±20%

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
