PANASONICEEEFN1E470R47μF Electrolytic Aluminium Electrolytic Capacitor 25V dc, Surface Mount - EEEFN1E470R

Điện dung 47µFĐường kính 5mmKhoảng cách chân 1.5mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1E470R
Thương hiệu
Quy cách đóng gói
Cuộn 1000 cái
Mã kho
2043389
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 47 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1E470R
Capacitance 47µF
Voltage 25V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 5 x 5.8mm
Length 5.8mm
Minimum Operating Temperature -55°C
Diameter 5mm
Maximum Operating Temperature +105°C
Lead Pitch 1.5mm
Polarised Polar
Series FN-V
Automotive Standard AEC-Q200
Ripple Current 160mA
Equivalent Series Resistance 700mΩ
Tolerance ±20%

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
