PANASONICEEEFN1E821UP820μF Electrolytic Aluminium Electrolytic Capacitor 25V dc, Surface Mount - EEEFN1E821UP

Điện dung 820µFĐường kính 10mmKhoảng cách chân 4.6mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1E821UP
Thương hiệu
Quy cách đóng gói
Cuộn 500 cái
Mã kho
2043393
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 820 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1E821UP
Capacitance 820µF
Voltage 25V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 10 (Dia.) x 10.2mm
Length 10.2mm
Minimum Operating Temperature -55°C
Diameter 10mm
Maximum Operating Temperature +105°C
Lead Pitch 4.6mm
Polarised Polar
Tolerance ±20%
Series FN-V
Automotive Standard AEC-Q200
Ripple Current 850mA
Equivalent Series Resistance 80mΩ

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
