PANASONICEEEFN1H151UP150μF Electrolytic Aluminium Electrolytic Capacitor 50V dc, Surface Mount - EEEFN1H151UP

Điện dung 150µFĐường kính 8mmKhoảng cách chân 3.1mmKiểu lắp Surface Mount
Mã nhà sản xuất
EEEFN1H151UP
Thương hiệu
Quy cách đóng gói
Cuộn 500 cái
Mã kho
2043405
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Panasonic aluminium electrolytic V type FN series capacitor is a vibration proof surface mount capacitor with 150 μF capacitance. This capacitor mostly used in applications like industrial, infrastructure and automotive applications.

life expectancy under temperature up to 105 ? is 2000 hours

AEC-Q200 compliant

THÔNG SỐ KỸ THUẬT
Manufacturer Panasonic
Manufacturer Part No. EEEFN1H151UP
Capacitance 150µF
Voltage 50V dc
Mounting Type Surface Mount
Technology Aluminium Electrolytic
Dimensions 8 x 10.2mm
Length 10.2mm
Minimum Operating Temperature -55°C
Diameter 8mm
Maximum Operating Temperature +105°C
Lead Pitch 3.1mm
Equivalent Series Resistance 340mΩ
Ripple Current 350mA
Tolerance ±20%
Polarised Polar
Series FN-V
Automotive Standard AEC-Q200

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
