RECOMRACM40-12S40W Embedded Switch Mode Power Supply SMPS, 12V dc, Enclosed, Medical Approved

Input Voltage 90 → 264 V ac✓ Medical ApprovedKiểu lắp Chassis MountNumber of Outputs 1
Mã nhà sản xuất
RACM40-12S
Thương hiệu
Quy cách đóng gói
1 cái
Mã kho
9039919
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

RECOM RACM40 40W Enclosed Case Style Single Output AC/DC Converters

The RECOM RACM40 is a compact 3.6"x2.38" high efficiency AC/DC power supply with 2xMOPP safety approval for medical applications. These space saving enclosed power supplies have an universal input voltage range (85-264VAC), 4kVAC isolation, require no minimum load and can be used at ambient temperatures of between -40°C and +85°C. The 12V, 15V, 24V or 48V output voltages are fully protected and have tolerances of less than ±0.2% over the entire input voltage range and less than ±0.5% over the entire load range. The RACM40 series is certified to medical safety standard IEC/ES/EN-60601-1 3rd Edition and feature BF rated outputs with less than 75μA leakage current. It has a built-in Class B EMI filter and comes with a long 5 year warranty.

2MOPP/250VAC

Suitable for built in Class II Applications

Certified to medical safety standard IEC/ES/EN-60601-1 3rd Edition

Wide Input Voltage Range (85-264VAC)

Low Leakage Current (<75μA)• 5000m Operation

-40°C to +85°C Operating Temperature

Approvals

Medical certified to IEC/ES/EN-60601-1 3rd Edition

EN-55011 Certified

EN-55022 Certified

THÔNG SỐ KỸ THUẬT
Manufacturer Recom
Manufacturer Part No. RACM40-12S
Output Voltage 12V dc
Output Current 3.333A
Power Rating 40W
Number of Outputs 1
Input Voltage 90 → 264 V ac
Mounting Type Chassis Mount
Package Type Enclosed
Length 89mm
Width 63.5mm
Medical Approved Yes
Depth 27mm
Series RACM40
Maximum Temperature +70°C
Weight 280g
Minimum Temperature -40°C

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
