RS PRO 18 Core CY Control Cable 0.75 mm², 50m, Screened; 827-4195
Mã kho: 8274195
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Cores | 18 |
| Cross Sectional Area | 0.75 mm² |
| Length | 50m |
| Current Rating | 0 |
| Outer Diameter | 12.1mm |
| Voltage Rating | 300/500 V |
| Sheath Colour | Grey |
| American Wire Gauge | 18 AWG |
| Earth Cable | Yes |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +80°C |
| Oil Resistant | Yes |
| Sheath Material | Polyvinyl Chloride PVC |
| Screen Type | Tinned Copper Braid |
| Conductor Resistance | 26 Ω/km |
| Filler Material | Non-Wicking Filler |
| Insulation Material | PVC |
| Screened/Unscreened | Screened |
| Minimum Bend Radius | Fixed - 6 x D Occasional Flexing - 20 x D |
| Conductor Material | Copper |
| Core Strands | 24/0.20 mm |
