SAMTECTSW-101-23-L-DHEADER TH 2POS 2.54MM

Hướng thân StraightSố chân 2Số hàng 2Bước chân 2.54mm
Mã nhà sản xuất
TSW-101-23-L-D
Thương hiệu
Quy cách đóng gói
1 cái
Mã kho
2001684
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The Samtec TSW series is a square post terminal strip. Insulating material is of black glass filled polyester. Terminals are of phosphor bronze. There are total 2 no. of contacts.

Plating used : Au or Sn over 50 μ" (1.27 μm) Ni

Operating temp range: -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin

Voltage Rating upto 550 VAC mated with SSW; 500 VAC mated with BCS or ESQ; 450 VAC -RA/-RE mated with BCS or SSM 400 VAC mated with CES

It is RoHS Compliant

THÔNG SỐ KỸ THUẬT
Series TSW
Pitch 2.54mm
Number of Contacts 2
Number of Rows 2
Body Orientation Straight
