SICKUD18-22CC242Through Beam Photoelectric Sensor, Cylindrical Sensor, 20 mm Detection Range

Frequency 400kHzSensing Range Max 60mm
Mã nhà sản xuất
UD18-22CC242
Thương hiệu
Quy cách đóng gói
1 cái
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Overview

The UD18-2 specializes in checking for double layers and splices using ultrasonic technology. Operating with precision, it is able to determine whether one, two or no material layers are present between its sender and receiver. Where the UD18-2 really excels is checking for double layers in paper, cardboard, shiny metal, and transparent plastic.

It is possible to teach in up to four sensitivity levels and switch between them during operation, allowing the sensor to tackle even the most complex of applications and ensure permanent system availability with a consistently excellent level of production quality.

At a glance

Material classifications: no layers, single layer, double layers

Plug-and-play

sensitivity levels that can be selected, taught in, and changed during operation

Up to four individual sensitivity levels

Variable mounting distance

LEDs visible from any direction

Immune to dirt, dust, and humidity

Your Benefit

Maximum productivity and quality thanks to reliable material transportation monitoring

Rapid commissioning thanks to plug-and-play plus a range of sensitivity levels to choose from

Easy to switch between sensitivity levels during operation, preventing downtimes during material changes

Individual teach-in of various materials, making it possible to tackle even the most demanding applications

The utmost flexibility during installation thanks to variable mounting distance

LEDs visible from any direction, making it easy to monitor double sheet detections

Reliable detection in dirty, dusty, and humid conditions thanks to the ultrasonic technology's immunity to these environments

Applications

Fields of applications

Double layer detection for paper, cardboard, film, sheet metal, wafers, PCBs, and chip cards

Checking material transportation upstream of presses, printing machines, and cutting machines

Splice and label detection

Packaging, process
