STMICROELECTRONICSSTSPIN840STSPIN840, DC Motor 3-phase AC Motor Driver, 48 V 1.5A 24-Pin, TFQFPN 4 x 4 x 1.05 - 24L

Maximum Collector Emitter Voltage 48VMaximum IGBT Collector Current 1.5AMaximum Output Current 1.5AMaximum Supply Voltage 48V
Mã nhà sản xuất
STSPIN840
Thương hiệu
Quy cách đóng gói
15 cái (băng liên tục)
Mã kho
2025541
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com 📄 Datasheet (PDF)

The STMicroelectronics Compact dual brushed DC motor driver is able to drive two bi-directional brushed DC motors simultaneously. It integrates, in a very small 4 x 4mm QFN package, both the control logic and a fully protected low RDSon dual full bridge power stage.

Current control with adjustable OFF time

Current sensing based on external shunt resistors

THÔNG SỐ KỸ THUẬT
Manufacturer STMicroelectronics
Manufacturer Part No. STSPIN840
Motor Type DC
Output Configuration Full Bridge
Maximum IGBT Collector Current 1.5A
Maximum Output Current 1.5A
Maximum Supply Voltage 48V
Maximum Collector Emitter Voltage 48V
Package Type TFQFPN 4 x 4 x 1.05 - 24L
Pin Count 24

Giá: Liên hệ – gửi mã và số lượng về CV@chanhvinh.com để nhận báo giá nhanh.
