TDK-Lambda, DRL-10 DIN Rail Power Supply, 24V dc Output Voltage, 420mA Output Current [DRL10-24-1]; 137-0854
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac |
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264V ac |
| Output Voltage | 24 V dc |
| Output Current | 420 mA |
| Power Rating | 10W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 91mm |
| Width | 18mm |
| Standards Met | IEC 60068-2-27, IEC 60068-2-6, UL 1310, UL 508, UL 60950-1 |
| Series | DRL-10 |
| Maximum Temperature | +71°C |
| Special Features | High In-Service Lifetime, Low No Load Consumption |
| Load Regulation | 240mV |
| Ripple And Noise | 240mV |
| Minimum Temperature | -20°C |
| Depth | 55.6mm |
| Mounting Type | DIN Rail Mount |
