WIKA12292886G 1/2in Bottom Entry Analogue Positive Pressure Gauge 1.6bar, 12292886

Connection Size G 1/2inGauge Outside Diameter 160mmMaximum Pressure Measurement 1.6barMinimum Pressure Measurement 0bar
Mã nhà sản xuất
12292886
Thương hiệu
Quy cách đóng gói
Each
Mã kho
2227382
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

The Wika manufactures and qualifies the pressure gauge in accordance with the standards EN 837-1 and ASME B40.100. This instrument has as safety function a blow-out device with blow-out plug on the back of the case. In the event of a failure, overpressure can escape there. This high-quality bourdon tube pressure gauge has been designed especially for the process industry. Maximum pressure 1.6 bar.

Excellent load-cycle stability and shock resistance

With case filling (model 233.50) for applications with high dynamic pressure loads and vibrations

Completely from stainless steel

Scale ranges from 0 … 0.6 to 0 … 1,600 bar

.THÔNG SỐ KỸ THUẬT:
Minimum Pressure Measurement 0bar
Maximum Pressure Measurement 1.6bar
Pressure Gauge Type Bottom Entry
Gauge Outside Diameter 160mm
Connection Size G 1/2in
