WIKA9052364Dial Pressure Gauge 60bar, 9052364

Gauge Outside Diameter 161mmMaximum Pressure Measurement 60barMinimum Pressure Measurement 0barPressure Gauge Type Dial
Mã nhà sản xuất
9052364
Thương hiệu
Quy cách đóng gói
Each
Mã kho
2229160
Liên hệ
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

The WIKA model 312.20 mechanical test gauge has been specifically designed for the measurement of pressures with high accuracy. With its accuracy class of 0.6, the Bourdon tube pressure gauge is suitable for testing industrial type pressure gauges or for precision measurement in laboratories. For the respective measuring requirement, a scale range between 0 ... 0.6 and 0 ... 600 bar can be selected. The model 312.20 is constructed with a case from stainless steel and wetted parts from copper alloy. The optimal readability of the instrument, with a nominal size of 160 mm, is achieved via a knife edge pointer and a dial with fine divisions. Supported through the optional mirror band scale, the parallax error can be eliminated.

Knife edge pointer for optimal accuracy of reading

Precise movement with wear parts of argentan

.THÔNG SỐ KỸ THUẬT:
Minimum Pressure Measurement 0bar
Maximum Pressure Measurement 60bar
Pressure Gauge Type Dial
Gauge Outside Diameter 161mm
